Jyoti Steels is a trustworthy maker and provider of high-grade Copper Nickel 70/30 Stud Bolts headquartered in Mumbai, India. Our Cu-Ni 70/30 fasteners are renowned far and wide for their remarkable resistance to corrosion, strength, and performance in offshore, marine, and chemical process industries. For resisting severe conditions, these stud bolts are produced with quality raw materials and up-to-date processes. Jyoti Steels believes in producing products of international quality and as per customer requirements, and offering safe and long-lasting fastening solutions to customers all over India and worldwide.
Copper Nickel 70/30 Stud Bolts consist of 70% Copper and 30% Nickel with minor additions of Iron (0.4–0.6%) and Manganese (0.4–1.0%) to enhance strength and corrosion resistance. These bolts have a tensile strength of 320–500 MPa, yield strength of 120–150 MPa, and elongation of 30–40%. Their density is about 8.95 g/cm³, with a melting point ranging from 1170°C to 1240°C. Cu-Ni 70/30 exhibits outstanding resistance to corrosion in seawater, erosion, and stress cracking, together with good heat conductivity, which makes these stud bolts well suited to high-pressure and saltwater-exposed applications.
| Specifications | ASTM B151 / ASME SB151 |
| Diameter | 1/4″-3″ Matric:M27 to M72 in length 2000mm |
| Dimensions | DIN 975/976, ASME B18.2.1, B18.31.3, B16.5 |
| DIN Standard | B.S. DIN 931, DIN 933, DIN 912, DIN 934, DIN 6923, DIN 603, DIN 7981, DIN 970, DIN916, DIN 7982, DIN 7985, DIN 913 |
| UTS | NPT, UNS, UNF, UNC, UNEF, NPTF |
| ISO | ISO 4033, ISO 4032, ISO 7380, ISO 4017, JIS standards |
| Threads | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Type | Cold Forged, Hot Forged, Bar Stock Machined, Bar Stock Milling |
| Element | Cu | Mn | Pb | Ni | Fe | Zn |
| Copper Nickel 70/30 | 65.0 min | 1 max | .05 max | 29-33 | 0.4-1.0 | 1 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Copper Nickel 70/30 | 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel 70/30 Stud Bolts in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper Nickel 70/30 Stud Bolts find widespread use in high saline and corrosive environment resistance applications. They are best suited for shipbuilding, offshore platforms, seawater cooling systems, and ballast water systems. They are also applied in condensers, heat exchangers, pumps, and valves in chemical and petrochemical processes. Their high strength and anti-biofouling characteristics make them suitable for desalination plants and coastal structures. They are used in power generation plants in high-temperature and high-humidity locations where corrosion resistance is paramount. They provide long-term, reliable fastening in applications where reliability and longevity are paramount.
