Jyoti Steels is a top-notch producer and distributor of Titanium Gr 4 Pipes in Mumbai, India, providing high-strength titanium solutions for demanding industrial purposes. Titanium Grade 4 is the strongest of the commercially pure grades and is highly valued for its superior corrosion resistance, moderate ductility, and weldability. Jyoti Steels provides the best quality product through accurate manufacturing and strict compliance with international norms. These pipes find best applications in aerospace, marine, chemical process, and medical applications, and the company meets domestic and export markets with quality and timely delivery.
Titanium Gr 4 Pipes are composed of Titanium (~98.9%), Iron (≤0.50%), Oxygen (≤0.40%), Carbon (≤0.08%), Nitrogen (≤0.05%), and Hydrogen (≤0.015%). Grade 4 possesses the greatest strength of commercially pure titanium grades with a tensile strength of around 550 MPa, yield strength of about 483 MPa, and elongation of around 15%. It possesses a density of 4.51 g/cm³, a melting temperature of around 1660°C, and thermal conductivity of ~14.6 W/m·K. These pipes contain good corrosion resistance, particularly in oxidizing and chloride-enriched atmospheres, and are ideal for structural and pressure-related applications demanding greater strength.
| Standards : | ASTM B862, B861 / ASME SB862, SB861 |
| Dimensional : | ANSI/ASME X6.19M, ANSI/ASME X6.10M |
| Seamless Pipe Size : | 1 / 2″ NB – 16″ NB |
| Welded Pipe Size : | 1 / 2″ NB – 24″ NB |
| Outside Diameter : | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock |
| Pipe Type : | Seamless / Welded / ERW / Fabricated / CDW / 100% X Ray Welded |
| Thickness Range : | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Pipes End : | Plain End, Beveled End, Treaded One End, TBE (Treaded Both Ends) |
| Value Added Services : | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| Grade | C | N | O | H | Ti | Fe |
| Titanium Grade 4 | .08 max | .05 max | .40 max | .015 max | Bal | .50 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Grade 4 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Grade 4 | 3.7065 | R50700 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Grade 4 Pipes in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Gr 4 Pipes find extensive applications in systems requiring high strength and corrosion resistance. They are employed in piping systems, heat exchangers, and pressure vessels for handling aggressive media in chemical and petrochemical processes. They are employed by the aerospace industry in hydraulic lines, engine parts, and structure components. They are suitable for desalination plants and seawater cooling in marine environments. Grade 4 pipes are also applied in medical implants and devices because of their biocompatibility. They are also applied in power generation and offshore sectors where strength and durability in extreme conditions are required.
