Jyoti Steels, a leading Mumbai, India-based manufacturer and supplier, specializes in supplying top-notch-quality Titanium Gr 8 Pipes for essential industrial uses. Titanium Grade 8, an alpha-stabilized palladium alloy, provides excellent corrosion resistance, particularly in severe reducing and oxidizing conditions. Jyoti Steels works towards supplying precision-engineered products that conform to international standards and requirements of performance. With an impeccable reputation for quality, dependability, and after-sales support, the company operates in chemical processing, marine, energy, and pharmaceutical industries in India and worldwide.
Titanium Gr 8 Pipes consist of about Titanium (~99.1%), Palladium (0.13%–0.25%), controlled amounts of Oxygen (≤0.13%), Iron (≤0.30%), Carbon (≤0.08%), Nitrogen (≤0.03%), and Hydrogen (≤0.015%). This alpha alloy provides tensile strength of approximately 550 MPa, yield strength of about 380 MPa, and elongation of approximately 18%. It possesses a density of 4.51 g/cm³ and a melting point of nearly 1665°C. Palladium addition greatly improves corrosion resistance in acidic and chloride environments, while its mechanical strength and stability qualify it for severe service conditions.
| Standards : | ASTM B862, B861 / ASME SB862, SB861 |
| Dimensional : | ANSI/ASME X6.19M, ANSI/ASME X6.10M |
| Seamless Pipe Size : | 1 / 2″ NB – 16″ NB |
| Welded Pipe Size : | 1 / 2″ NB – 24″ NB |
| Outside Diameter : | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock |
| Pipe Type : | Seamless / Welded / ERW / Fabricated / CDW / 100% X Ray Welded |
| Thickness Range : | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Pipes End : | Plain End, Beveled End, Treaded One End, TBE (Treaded Both Ends) |
| Value Added Services : | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| Grade | O | N | C | H | Fe | Al | Mo | V |
| 8Al 1Mo 1V | 0.15 | 0.05 | 0.08 | 0.0125 | 0.3 | 7.5-8.5 | 0.75-1.25 | 0.75-1.25 |
| Grade | Tensile strength (MPa) | Yield strength (MPa) | Elongation in 4D (%) | Reduction of area (%) | Hardness (HV) |
| 8Al 1Mo 1V | 1020 | 930 | 10 | 40 | 350 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 8 | – | R54810 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Grade 8 Pipes in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Gr 8 Pipes are used extensively where higher corrosion resistance and mechanical dependability are needed. In chemical processing, they find application in reactors, heat exchangers, and process lines for handling aggressive acids such as nitric and sulfuric acid. They are highly durable against seawater corrosion in marine and offshore applications. The energy sector utilizes them in cooling and condenser systems. Pharmaceutical and biomedical applications utilize Grade 8 pipes for equipment where resistance to aggressive sanitizing chemicals and cleanliness are required. They are also suited for applications in pulp & paper and electrochemical processing due to their strength and resistance.
