Jyoti Steels is a well-established maker and distributor of Hastelloy Check Valves in Mumbai, India. Famous for supplying high-precision flow control solutions, the organization has expertise in corrosion-resistant valves suited for high-pressure and aggressive applications. Jyoti Steels serves a variety of industries including chemical processing, pharmaceutical, petrochemicals, and marine. With focus on quality, strength, and global standards, their Hastelloy check valves guarantee effective flow control and backflow protection for critical systems. Customers from India and around the world count on Jyoti Steels for superior-performance valves designed to handle severe service conditions.
Chemical Composition, Mechanical and Physical Properties:
Hastelloy Check Valves, usually produced from grade C22, contain approximately 56% Nickel, 20–22.5% Chromium, 12.5–14.5% Molybdenum, 2–6% Iron, and 2.5–3.5% Tungsten, with minute traces of Cobalt (up to 2.5%) and Manganese (up to 0.5%). The valves offer tensile strength of approximately 690 MPa, yield strength of 283 MPa, and 45% elongation. Density is 8.69 g/cm³, and melting range is 1350°C to 1400°C. Hastelloy valves have good resistance to oxidizing and reducing agents, pitting, crevice corrosion, and retain mechanical strength under harsh chemical and thermal stresses.
Pressure : 3000,6000,9000 PSI
Type :BALL VALVES, CHECK VALVES, NEEDLE VALVES
Ends : MALE ADAPTORS, NPTF, BSPT
Size : 1/4” TO 3”
| Grade | C | Mn | Si | Co | S | Ni | Cr | Fe | Mo | W | V | P |
| Hastelloy C22 | 0.010 max | 0.50 max | 0.08 max | 2.5 max | 0.02 max | Bal | 20 – 22.5 | 2 – 6 | 12.5 – 14.5 | 2.5 – 3.5 | 0.35 max | 0.02 max |
| Hastelloy C276 | 0.010 max | 1.0 max | 0.08 max | 2.5 max | 0.03 max | Bal | 14.5 – 16.5 | 4 – 7 | 15 – 17 | 3 – 4.5 | 0.35 max | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Check Valve in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy Check Valves find wide application in safety-critical systems where prevention of backflow and corrosion is a requirement. They are utilized in pipelines transporting very corrosive fluids such as sulfuric acid, hydrochloric acid, and chlorine compounds in chemical processing facilities. Marine and offshore sectors apply them in seawater treatment systems because they resist saltwater corrosion. They provide hygienic fluid control in aggressive cleaning situations in the pharmaceutical and food industries. Power plants and refineries employ them in high-pressure and high-temperature lines. Their chemical resistance and durability qualify them for safe, reliable, and efficient flow control in adverse conditions.
