Jyoti Steels, Mumbai, India-based, is a premium manufacturer and supplier of Inconel Ball Valves, providing state-of-the-art flow control solutions for high-temperature and corrosive services. With a reputation for precision engineering and conformance to international standards, Jyoti Steels manufactures robust and leak-proof Inconel ball valves suitable for high-performance industries like oil & gas, chemical processing, power generation, and marine engineering. With emphasis on high quality, reliability, and timely delivery, Jyoti Steels provides valves that can consistently perform and last long even in most aggressive application conditions.
Inconel Ball Valves are usually constructed of high-performance Inconel alloys such as Inconel 625 or 718, engineered for high corrosion resistance and mechanical strength. The composition consists of Nickel (Ni) 58% min, Chromium (Cr) 20–23%, Molybdenum (Mo) 8–10%, Niobium + Tantalum (Nb + Ta) 3.15–4.15%, and Iron (Fe) ≤5%, with trace elements of Mn, Si, Al, and C ≤0.10%. These valves have a tensile strength of ~827 MPa, yield strength of ~414 MPa, and an elongation of 30%. Density is approximately 8.44 g/cm³ with a melting range of 1290–1350°C, making them well-suited for high-pressure and high-temperature applications.
| VALVE SIZE | 6 MM TO 50 MM or 1/8″ TO 2″ |
| SPECIFICATION | ASME B16.34, BS 5352, ASME SA494/ASTM A494 API 602, ASME B16.5, ASME B1.20.1, ASME B16.25, ASME B16.10, ASME B16.11, DIN3352 |
| CONNECTION | TUBE END, WELD NIPPLE,THREADED, SOCKET WELD, BUTT WELD, FLANGED, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 4 WAY, 3 WAY, 2 WAY, 5 WAY, |
| SEAL RING MATERIAL | PVDF, PTFE, PEEK, DELRIN, GRAPHITE |
| PRESSURE RATING | 15000 PSI, 3000 PSI, 1500 PSI, 10000 PSI, 6000 PSI, 20000 PSI |
| GRADE | INCONEL 625, 600, 800, 718, 825, ALLOY 20 |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| MEDIA | AIR, HYDRAULIC OIL, GAS, WATER, HOT WATER , STEAM, SEA WATER , COLD WATER , CHEMICAL |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS , |
| BODY TYPE | BAR STOCK |
| MEDIA TEMPERATURE | (-120* C – 500*C ) AS PER PRESSURE RANGE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Mn | Al-Ti | C | Si | S | Fe | Cr2 | Ni | |
| Inconel Ball Valve | min. | – | – | – | – | – | – | 20.0 | 58.0 |
| max. | 0.50 | 0.40 | 0.10 | 0.50 | 0.015 | 5.0 | 23.0 | – | |
| Grade | Strength of Yield 0.2% Proof (MPa) minimum | Elongation (% in 50mm) minimum | Strength of Tensile (MPa) minimum | Hardness | |
| Brinell (HB) maximum | Rockwell B (HR B) maximum | ||||
| Inconel Ball Valve | Psi – 75,000 , MPa – 517 | 42.5 | Psi – 1,35,000 , MPa -930 | – | – |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Inconel Ball Valve in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel Ball Valves are utilized across many industries demanding heat, corrosion, and pressure resistance. In the oil and gas sector, they are mounted on pipelines, offshore structures, and refineries to deal with hostile fluids and gases. In chemical processing, the valves play a crucial role in regulating flow in systems subjected to acids, solvents, and elevated temperatures. Inconel ball valves are utilized in steam, cooling, and turbine systems in power plants. They are also used in marine and aerospace applications where resistance to seawater or jet fuel and durability are critical. Their reliability makes them suitable for environmental and nuclear engineering applications.
