Jyoti Steels is a leading Hastelloy Ball Valves manufacturer and supplier in Mumbai, India, renowned for the supply of corrosion-resistant flow control solutions to various industries. Our Hastelloy ball valves are designed to provide high strength, accuracy, and reliability in severe chemical and marine environments. Produced from high-quality Hastelloy alloys, these valves find applications in critical use where there is a need for resistance against acids, oxidizing agents, and high-temperature conditions. Jyoti Steels is dedicated to quality assurance, timely delivery, and customer-centric service to Indian and overseas markets.
Hastelloy Ball Valves, which are usually produced from Hastelloy C-276 or C-22, have approximately 57% Nickel, 15–17% Molybdenum, 14.5–16.5% Chromium, 4–7% Iron, and 3–4.5% Tungsten. They also have traces of Cobalt (≤2.5%), Manganese, and Silicon. These valves have very good mechanical properties such as tensile strength of approximately 690 MPa and yield strength of 283 MPa. Their density is around 8.9 g/cm³, with a melting range of 1325–1370°C. Hastelloy valves offer excellent resistance to pitting, crevice corrosion, and stress corrosion cracking and are therefore best suited for extremely aggressive chemical and marine environments.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Mn | C | Co | S | Si | Cr | Ni | Mo | Fe | W |
| Alloy C22 | 0.50 max | 0.010 max | 2.5 max | 0.02 max | 0.08 max | 20 – 22.5 | Bal | 12.5 – 14.5 | 2 – 6 | 2.5 – 3.5 |
| Alloy C276 | 1.0 max | 0.010 max | 2.5 max | 0.03 max | 0.08 max | 14.5 – 16.5 | Bal | 15 – 17 | 4 – 7 | 3 – 4.5 |
| Element | Melting Point | Yield Strength (0.2%Offset) | Density | Tensile Strength | Elongation |
| Alloy C22 | 1399 °C (2550 °F) | Psi – 45000 , MPa – 310 | 8.69 g/cm3 | Psi – 1,00,000 , MPa – 690 | 45 % |
| Alloy C276 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | 8.89 g/cm3 | Psi – 1,15,000 , MPa – 790 | 40 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Ball Valve in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy Ball Valves find extensive applications in industries demanding high corrosion resistance and safe flow control. They are crucial in chemical processing plants, particularly in the handling of strong oxidizers, acids, and chlorides. These valves also find application in marine, wastewater treatment plants, pulp and paper, and pharmaceutical manufacturing. They are applied in oil & gas in refining and offshore platforms where there is a general exposure to aggressive chemicals. They are well suited for use in critical systems in harsh environments due to their durability, leak-free operation, and resistance to high temperatures and pressure.
