Jyoti Steels, Mumbai, India, is a reputed producer and supplier of high-quality Monel Ball Valves, which are renowned for their superior corrosion resistance and high-flow performance control. These valves, with international standards in mind, provide superior durability and leak-tight operation under harsh conditions. Jyoti Steels supplies to industries including marine, chemical processing, oil & gas, and power generation, offering precision-made Monel ball valves ensuring dependability in high-pressure, high-temperature, and corrosive service applications, thus a favored option for applications of prime importance.
Monel Ball Valves, generally made of Monel 400, consist of about Nickel (Ni) 63–70%, Copper (Cu) 28–34%), and Iron (Fe) up to 2.5%), Manganese (Mn) ≤2%), Silicon (Si) ≤0.5%), and Carbon (C) ≤0.3%). These valves have good mechanical strength, tensile strength between 480–620 MPa, yield strength around 170 MPa, and elongation of 30–40%. Their density is 8.8 g/cm³, and they are able to bear temperatures up to 1300–1350°C. Monel ball valves show excellent resistance to seawater, acids, and alkalis, which makes them highly reliable for corrosive and pressure applications.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Ni | Mn | C | Si | Cu | S | Fe | Cr |
| Monel 400 | 63.00 min | 2.00 max | 0.30 max | 0.50 max | 28.0-34.0 | 0.24max | 2.50 max | – |
| Element | Melting Point | Yield Strength (0.2%Offset) | Elongation | Density | Tensile Strength |
| Monel 400 | 1350 °C (2460 °F) | Psi – 35,000 , MPa – 240 | 40 % | 8.8 g/cm3 | Psi – 80,000 , MPa – 550 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Monel Ball Valve in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel Ball Valves have wide application across industries that call for strong control of flow through corrosive or high-pressure applications. In maritime, they find application in piping systems for seawater, fluid handling on ships, and oil platforms offshore. Chemical and petroleum chemical plants find application in corrosive acid and alkali handling process lines. In the petroleum & gas industry, these ball valves are used to control the flow in refinery, pipelines, and drilling units. Moreover, Monel ball valves find application in power generation plants, aerospace, and desalination plants, where durability, chemical resistance, and leak-free operation are paramount for safety and efficient operation.
