Jyoti Steels is a renowned Mumbai, India-based Titanium Ball Valve Manufacturer that specializes in providing precision-designed valves with superior performance in corrosive and high-pressure conditions. Jyoti Steels is committed to quality, longevity, and innovation and manufactures titanium ball valves that meet international standards and are well-suited to harsh industrial applications. Supported by sophisticated manufacturing facilities and skilled technical assistance, the company caters to various industry segments such as chemical, marine, aerospace, and power industries with dependable flow control solutions developed to satisfy even the most stringent operating conditions.
Titanium ball valves produced by Jyoti Steels are mostly composed of Titanium Grade 2 or Grade 5, with approximately 90% Titanium, 6% Aluminum, and 4% Vanadium (in the case of Grade 5), along with small amounts of Iron (≤0.3%) and Oxygen (≤0.2%). The valves possess very good mechanical strength with tensile strength between 345 MPa (Grade 2) and 895 MPa (Grade 5), and yield strength between 275 MPa and 828 MPa. They have a low specific gravity of 4.5 g/cm³ and a melting point of approximately 1660°C. The valves also have high corrosion resistance in seawater, acid, and oxidizing media, which can guarantee long-term performance.
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| STANDARD | ASTM B367, ASME B 16.10, BS EN 12266-1/API 598, ASME B 16.25, ASME B 16.5, BS1414/API 600, ASME B 16.34 |
| THREAD | BSPP, JIC, BSPT, METRIC, NPT, UNF |
| FUNCTION | 3 WAY, 2 WAY, 5 WAY, 4 WAY, |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
| PRESSURE RATING | 3000 PSI, 15000 PSI, 6000 PSI, 1500 PSI, 10000 PSI, 20000 PSI |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| EQUIVALENT BRANDS | PARKER, OLIVER VALVES, SWAGELOK, HAMLET, DK-LOK, HOKE |
| SEAL RING MATERIAL | PVDF, PTFE, PEEK, DELRIN, GRAPHITE |
| MEDIA | AIR, HYDRAULIC OIL, GAS, WATER, HOT WATER , STEAM, SEA WATER , COLD WATER ,CHEMICAL |
| BODY TYPE | BAR STOCK |
| MEDIA TEMPERATURE | (-120* C – 500*C )RANGE AS PER PRESSURE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Ti | C | O | H | N | Fe | Al | V |
| Ti Grade5 | 90 min | – | 0.2 max | – | – | 0.25 max | 6 min | 4 min |
| Ti Grade2 | 99.2 min | 0.1 max | 0.25 max | 0.015 max | 0.03 max | 0.3 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Ball Valve in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium ball valves are also utilized in applications where the strength, corrosion resistance, and lightweight properties of the material play important roles. They are commonly applied to chemical process plants, desalination plants, marine and offshore oil, aerospace fuel systems, and pharmaceutical companies. Such valves also have applications in power generation, pulp and paper, food processing, and oil and gas pipeline operations. Their capacity to cope with aggressive fluids and high temperatures under low maintenance makes them suitable for essential control systems. Titanium‘s biocompatibility also allows use in medical and biotech systems, providing flexible production of dependable flow control in various demanding environments.
