Jyoti Steels is a leading Duplex Manifold Valve manufacturer and supplier from Mumbai, India. Through its high dedication to quality and innovation, the company supplies a comprehensive line of premium-grade Duplex Manifold Valves designed to withstand tough applications and deliver superior performance. Engineered to satisfy the tough requirements of the oil & gas, petrochemical, and power generation sectors, Jyoti Steels produces all products to international standards. Supported by decades of experience and state-of-the-art manufacturing facilities, Jyoti Steels is a name to be relied upon in providing dependable valve solutions in India and overseas.
Duplex Manifold Valves are usually made up of around 22–23% Chromium, 4.5–6.5% Nickel, 2.5–3.5% Molybdenum, and 0.14–0.20% Nitrogen, with the rest being Iron and trace elements such as Manganese (<2%) and Silicon (<1%). They have a tensile strength of 620–850 MPa and yield strength of 450 MPa, with elongation of around 25%, mechanically. Physically, the valves show a density of 7.8 g/cm³, a melting point of about 1350°C, and superior resistance to chloride stress corrosion and pitting. These characteristics guarantee maximum performance in high-pressure and aggressive environments.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| ELEMENT | DUPLEX 31803 | DUPLEX 2205 |
|---|---|---|
| NI | 4.50 – 6.50 | 4.50 – 6.50 |
| C | 0.030 max | 0.030 max |
| N | 0.14 – 0.20 | 0.08 – 0.20 |
| P | 0.030 max | 0.030 max |
| MN | 2.00 max | 2.00 max |
| CR | 22.0 – 23.0 | 21.0 – 23.0 |
| S | 0.020 max | 0.20 max |
| MO | 3.0 – 3.5 | 2.50 – 3.50 |
| SI | 1.00 max | 1.00 max |
| FE | 63.72 min | 63.54 min |
| Grade | % Elongation | YS (MPa) | Hardness(BHN) | UTS (MPa) |
| 31803 | 25 min. | 450 min. | 293 max. | 620 min. |
| 2205 | 25 min. | 450 min. | 293 max. | 655 min. |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Needle Valve in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Duplex Manifold Valves are extensively employed where there is a need for high strength and resistance to corrosion. They are typically seen in offshore and onshore oil and gas facilities, chemical processing plants, desalination equipment, and power generation units. The valves are important in regulating the flow of fluids, instrument isolation, and safe maintenance procedures. Owing to their duplex stainless steel construction, they have superior resistance against aggressive media and high-pressure conditions, which is why they find applications in seawater, petrochemical distribution, and marine engineering. They are responsible for safer and more efficient industrial operations due to their reliability and durability.
