Jyoti Steels is a renowned manufacturer and supplier of Monel Manifold Valves in Mumbai, India. Recognized for providing high-quality corrosion-resistant valves, the company provides its services to demanding industries like marine, chemical processing, oil & gas, and power generation. Jyoti Steels applies advanced engineering practices and follows international standards to make each Monel manifold valve provide long-term durability, reliability, and precision. These valves are designed to function well in harsh pressure and corrosive conditions, making Jyoti Steels a reliable name in domestic as well as international industrial markets.
Monel Manifold Valves are generally manufactured from Monel 400 or Monel K500 alloys. Monel 400 consists of around Nickel 63%, Copper 28–34%, Iron 2.5%, Manganese 2%, Carbon 0.3%, and Silicon 0.5%. It has mechanical properties of tensile strength 550 MPa, yield strength 170 MPa, and elongation 35%. It has a density of 8.8 g/cm³ and a melting point of 1300–1350°C and also has good thermal conductivity. These valves are resistant to seawater corrosion, acids, and alkalis and are suitable for harsh chemical and marine environments, yet retaining structural integrity when under pressure.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Mn | C | Co | S | Si | Cr | Ni | Mo | Fe | W |
| Alloy C22 | 0.50 max | 0.010 max | 2.5 max | 0.02 max | 0.08 max | 20 – 22.5 | Bal | 12.5 – 14.5 | 2 – 6 | 2.5 – 3.5 |
| Alloy C276 | 1.0 max | 0.010 max | 2.5 max | 0.03 max | 0.08 max | 14.5 – 16.5 | Bal | 15 – 17 | 4 – 7 | 3 – 4.5 |
| Element | Melting Point | Yield Strength (0.2%Offset) | Density | Tensile Strength | Elongation |
| Alloy C22 | 1399 °C (2550 °F) | Psi – 45000 , MPa – 310 | 8.69 g/cm3 | Psi – 1,00,000 , MPa – 690 | 45 % |
| Alloy C276 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | 8.89 g/cm3 | Psi – 1,15,000 , MPa – 790 | 40 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Needle Valve in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel Manifold Valves find extensive application in marine engineering, offshore drilling operations, chemical processing plants, power generation plants, and oil & gas refineries. Because of their resistance to saline environments and corrosive chemicals, they are well suited for fluid flow control in corrosive and high-pressure systems. They find extensive application in instrumentation panels, hydraulic control systems, and process control assemblies. Their non-magnetic and hard–wearing characteristics also qualify them for defense and aerospace applications. These valves guarantee leak-proof performance, accurate flow control, and extended service life even under unstable temperature and aggressive chemical conditions.
