Jyoti Steels is a well-known Duplex Ball Valve manufacturer and supplier, headquartered in Mumbai, India. With intense focus on quality and innovation, the organization provides high-performance valve solutions appropriate for harsh industrial applications. These ball valves are produced from Duplex stainless steel, providing superior resistance to corrosion, pressure, and temperature variations. Jyoti Steels caters to oil & gas, petrochemicals, marine, and power generation industries. Their Duplex Ball Valves are engineered with precision to align with global specifications and provide long-life, leak-free, and efficient flow control in hostile service conditions.
Duplex Ball Valves are made of Duplex 2205 stainless steel consisting of 22% chromium, 5–6.5% nickel, 3–3.5% molybdenum, 0.14% nitrogen, and the rest balance iron. This alloy offers high resistance to pitting, stress corrosion cracking, and general corrosion. Mechanically, the valves possess tensile strength of 620–850 MPa, yield strength approximately 450 MPa, and elongation of 25%. Physical properties are a density of 7.8 g/cm³, melting point of 1350–1400°C, and thermal conductivity of 19 W/m·K. These properties render Duplex Ball Valves suitable for high-pressure, corrosive, and demanding applications.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| ELEMENT | DUPLEX 31803 | DUPLEX 2205 |
|---|---|---|
| NI | 4.50 – 6.50 | 4.50 – 6.50 |
| C | 0.030 max | 0.030 max |
| N | 0.14 – 0.20 | 0.08 – 0.20 |
| P | 0.030 max | 0.030 max |
| MN | 2.00 max | 2.00 max |
| CR | 22.0 – 23.0 | 21.0 – 23.0 |
| S | 0.020 max | 0.20 max |
| MO | 3.0 – 3.5 | 2.50 – 3.50 |
| SI | 1.00 max | 1.00 max |
| FE | 63.72 min | 63.54 min |
| Grade | UTS (MPa) | % Elongation | Hardness(BHN) | YS (MPa) |
| 31803 | 620 min. | 25 min. | 293 max. | 450 min. |
| 2205 | 655 min. | 25 min. | 293 max. | 450 min. |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Ball Valve in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Duplex Ball Valves are extensively utilized in oil and gas pipelines, chemical processing plants, and marine applications because they possess superior corrosion resistance and durability. They are well-suited for flow control in power generation, desalination plants, water treatment, and offshore drilling, where corrosive conditions and high pressure are prevalent. They are also well-applied in pulp and paper industries, firefighting apparatus, and fluid transport lines in industry. Their long lifespan, low maintenance requirements, and high reliability under harsh operating conditions make them a popular selection for high-performance fluid handling systems.
