Jyoti Steels, Mumbai, India, is a well-known manufacturer and supplier of high-grade Super Duplex Needle Valves, designed to meet the rigorous needs of sectors such as oil and gas, petrochemicals, and marine. Priced for their exceptional strength, corrosion resistance, and accuracy, Jyoti Steels makes sure every Super Duplex Needle Valve is designed to perform consistently under extreme pressure and temperatures. With emphasis on quality and customer satisfaction, they are a reliable ally for industries who need valves that can withstand tough environments and provide effective fluid control.
Super Duplex Needle Valves are made up of about 50-55% iron, 25-30% chromium, 3-5% nickel, 3-5% molybdenum, and trace amounts of nitrogen (0.1–0.3%) and tungsten. This alloy offers superior resistance to pitting, crevice corrosion, and stress corrosion cracking and thus finds applications in tough environments. Mechanically, Super Duplex Needle Valves have high tensile strength of 800–1000 MPa and yield strength of approximately 550 MPa, with elongation of 25%. It has a density of 7.8 g/cm³ and performs consistently even under high temperatures, providing leak-free operation over long periods in critical applications.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | S32760 | S32750 |
| Mn | 1.00 max | 1.20 max |
| Fe | 57.61 min | 58.095 min |
| C | 0.05 max | 0.030 max |
| Si | 1.00 max | 0.80 max |
| S | 0.010 max | 0.020 max |
| P | 0.030 max | 0.035 max |
| Cr | 24.00 – 26.00 | 24.00 – 26.00 |
| Ni | 6.00 – 8.00 | 6.00 – 8.00 |
| Mo | 3.00 – 4.00 | 3.00 – 5.00 |
| N | 0.20 – 0.30 | 0.24 – 0.32 |
| Melting Point (°C) | 1350 |
| Density (lb/in 3) | 0.281 |
| Density (g/cm 3) | 7.8 |
| Melting Point (°F) | 2460 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Needle Valve in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Needle Valves have broad application in the oil and gas industry to provide accurate control of fluids under high pressure and corrosive conditions, e.g., wellhead and refinery services. In the chemical industry, they find applications for the control of aggressive chemicals in reactors and pipelines. These valves are also used in power plants for fuel gas systems and in water treatment plants where reliability and corrosion resistance are paramount. They are also used in marine and offshore operations, providing secure and efficient fluid flow management under harsh conditions.
