Jyoti Steels is a premier Hastelloy Needle Valves manufacturer and supplier based in Mumbai, India. Known for their high-precision engineering and corrosion-resistant products, Jyoti Steels offers high-performance needle valves designed to suit harsh and demanding industrial applications. Produced in accordance with international standards, these valves are perfect for flow control in chemical, marine, and high-pressure systems. With a focus on quality, longevity, and performance, Jyoti Steels has gained a robust reputation for providing dependable and efficient flow control solutions that match the stringent requirements of different process industries.
Hastelloy Needle Valves are mostly fabricated from Hastelloy C276 alloy, which consists of Nickel ~57%, Molybdenum 15–17%, Chromium 14.5–16.5%, Iron 4–7%, Tungsten 3–4.5%, and trace amounts like Cobalt <2.5%, Carbon <0.01%, and Silicon <0.08%. These valves possess superior mechanical properties with tensile strength of 690 MPa (min), yield strength of 283 MPa (min), and elongation of approximately 40–45%. They are physically characterized by a density of 8.89 g/cm³ and a melting point of 1370°C. Their superior chemical composition provides superior resistance to corrosion, pitting, and cracking in highly corrosive and fluctuating pressure conditions.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Mn | C | Co | S | Si | Cr | Ni | Mo | Fe | W |
| Alloy C22 | 0.50 max | 0.010 max | 2.5 max | 0.02 max | 0.08 max | 20 – 22.5 | Bal | 12.5 – 14.5 | 2 – 6 | 2.5 – 3.5 |
| Alloy C276 | 1.0 max | 0.010 max | 2.5 max | 0.03 max | 0.08 max | 14.5 – 16.5 | Bal | 15 – 17 | 4 – 7 | 3 – 4.5 |
| Element | Melting Point | Yield Strength (0.2%Offset) | Density | Tensile Strength | Elongation |
| Alloy C22 | 1399 °C (2550 °F) | Psi – 45000 , MPa – 310 | 8.69 g/cm3 | Psi – 1,00,000 , MPa – 690 | 45 % |
| Alloy C276 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | 8.89 g/cm3 | Psi – 1,15,000 , MPa – 790 | 40 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Needle Valve in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy Needle Valves are applied widely in chemical processing, oil and gas refineries, marine, power generating plants, and pollution control systems. They find applications where aggressive fluids like acids, alkalis, and chlorides are handled. They are typically fitted in instrumentation lines, pressure regulation units, analytical equipment, and flow control panels. Their resistance to high temperature and pressure, combined with their leak-free construction, render them indispensable for safe and precise flow control in major industrial operations, such as offshore, petrochemical, and pharmaceutical processes.
