Jyoti Steels is a prominent manufacturer and exporter of Duplex Needle Valves, operating from Mumbai, India. It is renowned for its accuracy in engineering and quality, offering high-performance Duplex Needle Valves that are suitable for critical service. The valves are used to control flow with high precision, particularly in systems that handle corrosive or high-pressure media. Jyoti Steels applies sophisticated manufacturing methods and rigorous quality control to provide each valve in accordance with international standards, and thus they become a reliable solution for various industries such as oil & gas, petrochemicals, and marine engineering.
Duplex Needle Valves are made from duplex stainless steel, generally containing 22–23% Chromium, 4.5–6.5% Nickel, 2.5–3.5% Molybdenum, and 0.14–0.20% Nitrogen, with the balance Iron and trace elements like Manganese (<2%) and Silicon (<1%). The valves possess high tensile strength of 620–850 MPa and yield strength of about 450 MPa with about 25% elongation. Physically, they possess a density of 7.8 g/cm³, a melting point of approximately 1350°C, and superior corrosion resistance. Their duplex microstructure provides enhanced resistance to stress corrosion cracking and pitting with guaranteed long-term performance in aggressive environments.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| ELEMENT | DUPLEX 31803 | DUPLEX 2205 |
|---|---|---|
| NI | 4.50 – 6.50 | 4.50 – 6.50 |
| C | 0.030 max | 0.030 max |
| N | 0.14 – 0.20 | 0.08 – 0.20 |
| P | 0.030 max | 0.030 max |
| MN | 2.00 max | 2.00 max |
| CR | 22.0 – 23.0 | 21.0 – 23.0 |
| S | 0.020 max | 0.20 max |
| MO | 3.0 – 3.5 | 2.50 – 3.50 |
| SI | 1.00 max | 1.00 max |
| FE | 63.72 min | 63.54 min |
| Grade | % Elongation | YS (MPa) | Hardness(BHN) | UTS (MPa) |
| 31803 | 25 min. | 450 min. | 293 max. | 620 min. |
| 2205 | 25 min. | 450 min. | 293 max. | 655 min. |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Needle Valve in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Duplex Needle Valves find broad application in applications requiring accurate control of flow in high-pressure corrosive conditions. Typical applications cover oil and gas refineries, chemical plants, desalination plants, hydraulic, and instrumentation systems. Such valves are excellent for controlling liquid and gas flows with minimal leaks, even at harsh conditions. Their duplex stainless steel content provides greater resistance against chloride-induced corrosion, and they find applications in marine and offshore environments. They also have pharmaceutical, power generation, and water treatment plant applications where durability and accuracy are key considerations.
