Mumbai-based India’s Jyoti Steels is one of the largest suppliers and makers of Inconel Manifold Valves that provide high-duty valve solutions to support critical fluid control systems. The company’s expertise in precise engineering and high-international standards ensures that their Inconel manifold valves serve consistently well at very high temperatures and pressures. These valves are best suited for use in oil & gas, chemical processing, power plant, and aerospace applications, where corrosion resistance, strength, and leak-tight operation are crucial to system integrity and safety.
Inconel Manifold Valves, which are normally produced using Inconel 625 or 718, exhibit higher strength and corrosion resistance. Their chemical composition consists of Nickel (Ni) 50–63%, Chromium (Cr) 20–23%), Molybdenum (Mo) 8–10%), Niobium + Tantalum (Nb + Ta) 3.15–5.5%), and Iron (Fe) ≤5%), with minor amounts of Titanium, Aluminum, and Carbon ≤0.08%. These valves provide tensile strength up to 1240 MPa, yield strength approximately 1030 MPa, and elongation of 12–30%. With a specific gravity of 8.44 g/cm³ and a melting point of 1290–1350°C, Inconel manifold valves possess mechanical strength in thermal and chemical stress.
| MATERIAL | INCONEL |
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| ORIFICE SIZE | 2 MM – 9.5 MM |
| FLOW PATTERN | ANGLE, STRAIGHT, CROSS PATTERNS |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGE END |
| BODY SHAPE | ROUND, SQUARE, HEXAGON |
| PRESSURE RATING | 15,000 PSI, 3000 PSI, 1500 PSI, 10000 PSI, 6000 PSI, 20000 PSI |
| FUNCTION | 3 WAY, 2 WAY |
| BODY TYPE | FORGED, BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| MEDIA | AIR, HYDRAULIC OIL, GAS, WATER, HOT WATER , STEAM, SEA WATER , COLD WATER , CHEMICAL |
| MEDIA TEMPERATURE | (-120* C – 500*C ) AS PER PRESSURE RANGE |
| HANDLE | KNOB HANDLE, BAR T-HANDLE, WHEEL HANDLE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Cr | C | Mn | Si | S | Ni | Cu | Fe |
| Inconel 625 | 20.0 – 23.0 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | 58.0 min | 1.00 max | 5.0 max |
| Elongation in 2 “ (%) | .2% Yield (psi) | Temp° F | Tensile (psi) |
|---|---|---|---|
| 45 | 61,000 | 800 | 131,500 |
| 59 | 58,500 | 1400 | 78,000 |
| 45 | 66,000 | 400 | 134,000 |
| 44 | 84,000 | 70 | 144,000 |
| 48 | 60,500 | 1000 | 130,000 |
| 42.5 | 63,000 | 600 | 132,000 |
| 34 | 60,000 | 1200 | 119,000 |
| 117 | 39,000 | 1600 | 40,000 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Inconel Manifold Valve in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel Manifold Valves find application in high-performance applications involving strict control and resistance to hostile environments. In the oil industry, they find application in instrumentation systems, offshore platforms, and high-pressure control lines. Chemical plants utilize them to handle corrosive acids and toxic fluids. In power generation, including nuclear plants, these valves find application in steam and feedwater systems. Aerospace and marine industries also use them for fuel control and hydraulics. Their resistance to pitting, oxidation, and thermal cycling, as well as their durability, make them crucial for mission-critical fluid control.
